东芝全封闭外部风扇、防滴保护型电机
东芝全封闭外部风扇、防滴保护型电机
项目 |
解说 |
||
外壳构造 |
防滴保护型 |
全封闭外部风扇型 |
|
保护方式 |
IP22 |
IP55 |
|
安装方式 |
底脚 |
地面安装为标准型。其他还有轴垂直、墙壁安装、天井安装等方式 |
|
法兰盘 |
轴水平为标准型。其他还有轴向下、轴向上安装。 |
||
特征 |
从垂直方向到15°以内落下的水滴不会对电机产生不利影响的构造。并且，手指等无法触碰到电机内旋转部分或导电部分、超过12mm直径的固体无法侵入的构造。 |
电动机内的空气与外部空气不流通、外部完全封闭的全封闭型。在电机旋转轴上安装风扇来冷却外表的构造。 |
|
用途 |
可使用在湿度85%以下的环境、空气良好的室内环境。广泛使用于泵、风机、各种工作机械、一般用工业机械等。 |
室内，湿度100%以下，尘埃比较多的周围环境恶劣的场所内均可使用。多用于水泥、制粉、纺织、土木、建筑现场等环境。 |
|
全封闭外部风扇型(底脚安装 380V/50Hz）机种一览（红色为计划生产机种）
极数 |
输出(KW) |
机座号 |
形式记号 |
2 |
0.37 |
71M |
IKH-FCKK8G |
0.4 |
71M |
IKH-FCKK8G |
|
0.55 |
80M |
IKH-FCKK8G |
|
0.75 |
80M |
IKH-FCKK8G |
|
1.1 |
90L |
IKH-FCKA21 |
|
1.5 |
90L |
IKH-FCKA21 |
|
2.2 |
90L |
IKH-FCKA21 |
|
3 |
112M |
IKH-FCKA21 |
|
3.7 |
112M |
IKH-FCKA21 |
|
4 |
112M |
IKH-FCKA21 |
|
5.5 |
132S |
IKKH-FCKA21 |
|
7.5 |
132S |
IKKH-FCKA21 |
|
11 |
160M |
IKKH-FCK8G |
|
15 |
160M |
TKKH-FCK8G |
|
18.5 |
160L |
TKKH-FCK8G |
|
22 |
D180M |
FBFC |
|
30 |
D200L |
FBFC |
|
37 |
D200L |
FBFC |
|
45 |
D225M |
FBFC |
|
55 |
250M |
TKKH-FCK31 |
|
75 |
280S |
TKKH-FCK31 |
|
90 |
280M |
TKKH-FCK31 |
|
110 |
315S |
TKKH-FCK31 |
|
132 |
315M |
TKKH-FCK31 |
|
160 |
315L1 |
TKKH-FCK31 |
|
200 |
315L2 |
TKKH-FCK31 |
|
250 |
355M |
TKKH-FCK31 |
|
315 |
355L |
TKKH-FCK31 |
|
4 |
0.37 |
71M |
IKH-FBKK8G |
0.4 |
71M |
IKH-FBKK8G |
|
0.55 |
80M |
IKH-FBKK8G |
|
0.75 |
80M |
IKH-FBKK8G |
|
1.1 |
90L |
IKH-FBKA21 |
|
1.5 |
90L |
IKH-FBKA21 |
|
2.2 |
100L |
IKH-FBKA21 |
|
3 |
112M |
IKH-FBKA21 |
|
3.7 |
112M |
IKH-FBKA21 |
|
4 |
112M |
IKH-FBKA21 |
|
5.5 |
132S |
IKKH-FBKA21 |
|
7.5 |
132M |
IKKH-FBKA21 |
|
11 |
160M |
IKKH-FBK8G |
|
15 |
160L |
TKKH-FBK8G |
|
18.5 |
D180M |
FBFC |
|
22 |
D180L |
FBFC |
|
30 |
D200L |
FBFC |
|
37 |
D225S |
FBFC |
|
45 |
D225M |
FBFC |
|
55 |
250M |
TKKH-FCK31 |
|
75 |
280S |
TKKH-FCK31 |
|
90 |
280M |
TKKH-FCK31 |
|
110 |
315S |
TKKH-FCK31 |
|
132 |
315M |
TKKH-FCK31 |
|
160 |
315L1 |
TKKH-FCK31 |
|
200 |
315L2 |
TKKH-FCK31 |
|
250 |
355M |
TKKH-FCK31 |
|
315 |
355L |
TKKH-FCK31 |
|
6 |
15 |
D180L |
FBFC |
18.5 |
D200L |
FBFC |
|
22 |
D200L |
FBFC |
|
30 |
D225M |
FBFC |
|
37 |
250M |
TKKH-FCK31 |
|
45 |
280S |
TKKH-FCK31 |
|
55 |
280M |
TKKH-FCK31 |
|
75 |
315S |
TKKH-FCK31 |
|
90 |
315M |
TKKH-FCK31 |
|
110 |
315L1 |
TKKH-FCK31 |
|
132 |
315L2 |
TKKH-FCK31 |
|
160 |
355M1 |
TKKH-FCK31 |
|
200 |
355M2 |
TKKH-FCK31 |
|
250 |
355L |
TKKH-FCK31 |
全封闭外部风扇型（法兰盘安装形 380V/50Hz）机种一览（红色为计划生产机种）
| 极数 | 输出(KW) |
机座号 |
法兰盘 |
形式记号 |
安装方式 |
2 |
0.37 |
71M |
FF130 |
IKH-FCKLK8G |
|
0.4 |
71M |
FF130 |
IKH-FCKLK8G |
||
0.55 |
80M |
FF165 |
IKH-FCKLK8G |
||
0.75 |
80M |
FF165 |
IKH-FCKLK8G |
||
1.1 |
90L |
FF165 |
IKH-FCKLA21 |
||
1.5 |
90L |
FF165 |
IKH-FCKLA21 |
||
2.2 |
90L |
FF165 |
IKH-FCKLA21 |
||
3 |
112M |
FF215 |
IKH-FCKLA21 |
||
3.7 |
112M |
FF215 |
IKH-FCKLA21 |
||
4 |
112M |
FF215 |
IKH-FCKLA21 |
||
5.5 |
132S |
FF265 |
IKKH-FCKLA21 |
||
7.5 |
132S |
FF265 |
IKKH-FCKLA21 |
||
11 |
160M |
FF300 |
IKKH-FCKL8G |
||
15 |
160M |
FF300 |
TKKH-FCKL8G |
||
18.5 |
160L |
FF300 |
TKKH-FCLK8G |
||
22 |
D180M |
FF300 |
FBFC-D |
||
30 |
D200L |
FF350 |
FBFC-D |
||
37 |
D200L |
FF350 |
FBFC-D |
||
45 |
D225M |
FF400 |
FBFC-D |
||
55 |
250M |
FF500 |
TKKH-FCKL31 |
|
|
75 |
280S |
FF500 |
TKKH-FCKL31 |
||
90 |
280M |
FF500 |
TKKH-FCKL31 |
||
110 |
315S |
FF600 |
TKKH-FCKL31 |
||
132 |
315M |
FF600 |
TKKH-FCKL31 |
||
160 |
315L1 |
FF600 |
TKKH-FCKL31 |
||
200 |
315L2 |
FF600 |
TKKH-FCKL31 |
||
250 |
355M |
FF740 |
TKKH-FCKL31 |
||
315 |
355L |
FF740 |
TKKH-FCKL31 |
||
4 |
0.37 |
71M |
FF130 |
IKH-FCKLK8G |
|
0.4 |
71M |
FF130 |
IKH-FCKLK8G |
||
0.55 |
80M |
FF165 |
IKH-FCKLK8G |
||
0.75 |
80M |
FF165 |
IKH-FCKLK8G |
||
1.1 |
90L |
FF165 |
IKH-FCKLA21 |
||
1.5 |
90L |
FF165 |
IKH-FCKLA21 |
||
2.2 |
100L |
FF215 |
IKH-FCKLA21 |
||
3 |
112M |
FF215 |
IKH-FCKLA21 |
||
3.7 |
112M |
FF215 |
IKH-FCKLA21 |
||
4 |
112M |
FF215 |
IKH-FCKLA21 |
||
5.5 |
132S |
FF265 |
IKKH-FCKLA21 |
||
7.5 |
132M |
FF265 |
IKKH-FCKLA21 |
||
11 |
160M |
FF300 |
IKKH-FCKL8G |
||
15 |
160L |
FF300 |
TKKH-FCKL8G |
||
18.5 |
D180M |
FF300 |
FBFC-D |
||
22 |
D180L |
FF300 |
FBFC-D |
||
30 |
D200L |
FF350 |
FBFC-D |
||
37 |
D225S |
FF400 |
FBFC-D |
||
45 |
D225M |
FF400 |
FBFC-D |
||
55 |
250M |
FF500 |
TKKH-FCKL31 |
|
|
75 |
280S |
FF500 |
TKKH-FCKL31 |
||
90 |
280M |
FF500 |
TKKH-FCKL31 |
||
110 |
315S |
FF600 |
TKKH-FCKL31 |
||
132 |
315M |
FF600 |
TKKH-FCKL31 |
||
160 |
315L1 |
FF600 |
TKKH-FCKL31 |
||
200 |
315L2 |
FF600 |
TKKH-FCKL31 |
||
250 |
355M |
FF740 |
TKKH-FCKL31 |
||
315 |
355L |
FF740 |
TKKH-FCKL31 |
||
6 |
15 |
D180L |
FF300 |
FBFC-D |
|
18.5 |
D200L |
FF350 |
FBFC-D |
||
22 |
D200L |
FF350 |
FBFC-D |
||
30 |
D225M |
FF400 |
FBFC-D |
||
37 |
250M |
FF500 |
TKKH-FCKL31 |
|
|
45 |
280S |
FF500 |
TKKH-FCKL31 |
||
55 |
280M |
FF500 |
TKKH-FCKL31 |
||
75 |
315S |
FF600 |
TKKH-FCKL31 |
||
90 |
315M |
FF600 |
TKKH-FCKL31 |
||
110 |
315L1 |
FF600 |
TKKH-FCKL31 |
||
132 |
315L2 |
FF600 |
TKKH-FCKL31 |
||
160 |
355M1 |
FF740 |
TKKH-FCKL31 |
||
200 |
355M2 |
FF740 |
TKKH-FCKL31 |
||
250 |
355L |
FF740 |
TKKH-FCKL31 |
防滴保护型（380V/50Hz、底脚安装）机种一览（受注生产）
极数 |
输出(KW) |
机座号 |
形式记号 |
2P
|
0.75KW |
80M |
IK-DCKK8 |
1.5KW |
90L |
IK-DCKK8 |
|
2.2KW |
90L |
IK-DCKK8 |
|
4P
|
0.75KW |
80M |
IK-DBKK8 |
1.5KW |
90L |
IK-DBKK8 |
|
2.2KW |
100L |
IK-DBKK8 |
|
6P
|
0.75KW |
90L |
IK-DBKK8 |
1.5KW |
100L |
IK-DBKK8 |
